The print accuracy is as high as 2400dpi. Color and white ink can be printedsimultaneously with clear patterns and brilliant colors.
Support Media with a Width of 600mm and a Height of 3mm. Design printingsize freely. Achieves bright colors and high-definition printing to meet yourpersonalized needs for various custom apparel.
Equipped with ink string, filtering, and ink level detecting & reminding functionsto ensure smooth ink supply. You can check the ink balance at anytime withtransparent ink cartridge, make it more convenient to add ink.
Optional for fluorescent color CMYK+W+FM+FY+FG+FO printing, with independentink cartridge, built-in white ink circulation function, intelligent alarm ink cartridge.
Ensures smooth transmission without shifting, and film take-up system is easyto operate.Ensures higher step accuracy and maximum print quality.
Model No.
Ultra i3200 0602 DTF
Printhead
2 x EPSON i3200
Resolution
2400 dpi Max.
Ink Color
CMYK + White
Media
Size
60 cm
Type
PET Film
Speed
4 Pass
10 sqm/h
6 Pass
6 sqm/h
8 Pass
4 sqm/h
Ink Type
Pigment Ink
Ink Dropsize
1.5-21 pl Variable
Cleaning
Automatic Cleaning, Anti-Clogging Flash Function & Capping System
Feeding & Take-up System
Automatic Meida Feeding & Take-up Systems
Enironment
Tenperature 20-28℃, Humidity: 40-60%
RIP Software
Maintop / Photoprint
Interface
USD 3.0
Power
50/60 HZ, 220V
✱About 10% speed may vary from different feather printing mode and different PC configurations. All data are subject to change without prior notice.
