Model	UV Ultra i3200 1706UV
Printing Technology	UV Printing
Print Head	EPSON i3200
Acceptable Media	Type	Back-lit flex, Soft film, Wall cloth, Wall paper, PP, Vinly etc.
	Width	≦1620mm
Ink Type	UV Ink: CMYK W
Ink Supply	Negative Pressure Ink Supply
Ink Cartridges	Capacity	Color Siphon+White ink auto-stirring
	Color	CMYK+WW+CMYK
Image Format	Tiff, JPEG, EPS, PDF
RIP Software	Maintop(standard) Photoprint/ Print Factory(optional)
Printing Resolution	Maximum
Speed	Printing Mode	6H
	Production	40㎡/h
	Standard	25㎡/h
	High Resolution	15㎡/h
Ink Drying Method	UV Drying
Control System	Win10
Power	3000W
Interface	USB3.0 / Gigabit Ethernet
Power Supply	AC 220V±10%, 50/60 HZ
UPS	3KVA
Packing Dimension	Inch	L:129.92 x W: 44.10 x H: 43.31 1 Inch=25.4 mm
	Meter	L：3.3m x W: 1.12m x H: 1.1m
Printer Dimension	Inch	L：153.54 x W: 41.34 x H: 68.90 1 Inch=25.4 mm
	Meter	L:3.9m x W: 1.05m x H: 1.75m
Weight	G.W	1078 lb. 490 kg 1kg=2.2 lb.
	N.W	880 lb. 400 kg 1kg=2.2 lb.
Environment	Power On	Temperature 59℉ to 90 ℉[15℃ to 32℃ ] Humidity:35 to 80% (No Condensation)
	Power Off	Temperature 41℉ to 104 ℉[5℃ to 40℃ ] Humidity:35 to 80% (No Condensation)
Safety Certification	CE Certified

Wit-Color NEW Design UV printer Ulltra i3200 1706UV
